Inbouwkast 580X420X200MM RVS
Artikelreferentie: M18427
MENNEKES flush mounted distributor protection type IP43
1 stainless steel enclosure 1.4301, with trim frame 580 x 420 x 210 mm (h x w x d)
flush mounted enclosure 520 x 360 x 200 mm (h x w x d)
front door and trim frame: stainless steel brushed, K240
flush mounted enclosure: stainless steel bare
2 x din rain in the enclosure bottom
3 x cable entry bush at the top and
1 x at the bottom suited for cable diameters 13 - 36 mm
front door with semi sectional cylinder
drawing no. 1MB430
hint:
connection terminal cover plate 18421000 extra,
assembly plate 18416 extra
attention:
At site care has to be taken of a sufficient seal between trim frame and wall
1 stainless steel enclosure 1.4301, with trim frame 580 x 420 x 210 mm (h x w x d)
flush mounted enclosure 520 x 360 x 200 mm (h x w x d)
front door and trim frame: stainless steel brushed, K240
flush mounted enclosure: stainless steel bare
2 x din rain in the enclosure bottom
3 x cable entry bush at the top and
1 x at the bottom suited for cable diameters 13 - 36 mm
front door with semi sectional cylinder
drawing no. 1MB430
hint:
connection terminal cover plate 18421000 extra,
assembly plate 18416 extra
attention:
At site care has to be taken of a sufficient seal between trim frame and wall
- Gewicht:
- 14,600 kg / stuk
- Behoort tot:
- RVS behuizingen
- Beschermingsgraad:
- IP43
- Kleur behuizing:
- Grijs
- Wijze van plaatsen:
- Inbouw
- Grondstof:
- RVS
- Behoort tot:
- RVS behuizingen
- CEE 32A, 4P, 400V:
- 0
