DELTA-BOX 2CEE16A5P400V 1NF IP44
Artikelreferentie: M92916NF
MENNEKES DELTA-BOX ready wired for installation enclosure protection type IP 44
enclosure:
1 enclosure made of polycarbonate grey RAL 7035
fitted with/ fused with:
2 CEE receptacles 16A 5p 400V (one the left side and one at the bottom)
1 SCHUKO receptacle 16A 2p +E 230V french beld. system with shutter (mounted with flange on the right side)
cable entry/ supply:
1 M 32 x 1,5 with gland
terminal for 1 cable up to 5 x 10 mm²
with internal strain relief clamp
and installed hanging hook
1 hanging clip (loose)
enclosure:
1 enclosure made of polycarbonate grey RAL 7035
fitted with/ fused with:
2 CEE receptacles 16A 5p 400V (one the left side and one at the bottom)
1 SCHUKO receptacle 16A 2p +E 230V french beld. system with shutter (mounted with flange on the right side)
cable entry/ supply:
1 M 32 x 1,5 with gland
terminal for 1 cable up to 5 x 10 mm²
with internal strain relief clamp
and installed hanging hook
1 hanging clip (loose)
- Gewicht:
- 1,062 kg / stuk
- Behoort tot:
- DELTA-BOX
- Beschermingsgraad:
- IP44
- Kleur behuizing:
- Lichtgrijs
- Aansluittechniek:
- 1 terminal
- Type beschermcontact:
- Penaarde
- Kinderveiligheid:
- Ja
- Wijze van plaatsen:
- Ophangbaar
- CEE 16A, 5P, 400V:
- 2
- Contactdoos 16A, 2P+PE, 230V:
- 1
- Met bescherm toestellen:
- Neen
- Grondstof:
- Polycarbonaat
- Aantal geleiders:
- 1 kabel 5x10mm²
- Behoort tot:
- DELTA-BOX
- CEE 32A, 4P, 400V:
- 0
