AMAXX DUO63A5P400V+CEE32A,16A5P400V+2NF+
Artikelreferentie: M952082
MENNEKES receptacle combination unit AMAXX ready wired for installation enclosure protection Type IP 44
enclosure:
fusing fitted on pull out DIN rails below transparent window
window open downwards and can be locked with padlock
receptacles with angled plugging direction
fitted with/fused with:
1 CEE receptacle 63A 5p 400V (IP 44) switched with mechanical DUO-interlock
1 CEE receptacle 32A 5p 400V
1 MCB 32A 3p+N C
1 CEE receptacle 16A 5p 400V
1 MCB 16A 3p+N C
2 grounding-type receptacles 16A 2p+E 230V french/belgian system, with shutter
1 MCB 16A 1p+N C (ABB)
1 RCD 63A 4p IFN= 0,03 A
cable entry/supply
2 M 40 at the top and at the bottom (closed)
2 M 20 at the top and at the bottom (closed)
terminal for 2 cables up to 5 x 25 mm² (flexible max. 16mm²)
Receptacle combination acc. to IEC 61439:
Fuse 63 A
RDF 0,75
InA 63 A
enclosure:
fusing fitted on pull out DIN rails below transparent window
window open downwards and can be locked with padlock
receptacles with angled plugging direction
fitted with/fused with:
1 CEE receptacle 63A 5p 400V (IP 44) switched with mechanical DUO-interlock
1 CEE receptacle 32A 5p 400V
1 MCB 32A 3p+N C
1 CEE receptacle 16A 5p 400V
1 MCB 16A 3p+N C
2 grounding-type receptacles 16A 2p+E 230V french/belgian system, with shutter
1 MCB 16A 1p+N C (ABB)
1 RCD 63A 4p IFN= 0,03 A
cable entry/supply
2 M 40 at the top and at the bottom (closed)
2 M 20 at the top and at the bottom (closed)
terminal for 2 cables up to 5 x 25 mm² (flexible max. 16mm²)
Receptacle combination acc. to IEC 61439:
Fuse 63 A
RDF 0,75
InA 63 A
- Gewicht:
- 9,800 kg / stuk
- Soort artikel:
- 5 segmenten
- Behoort tot:
- AMAXX®
- Beschermingsgraad:
- IP44
- Kleur behuizing:
- Lichtgrijs
- Aansluittechniek:
- 1 terminal
- Type beschermcontact:
- Penaarde
- Kinderveiligheid:
- Ja
- Wijze van plaatsen:
- Opbouw
- CEE 32A, 5P, 400V:
- 1
- CEE 16A, 5P, 400V:
- 1
- Contactdoos 16A, 2P+PE, 230V:
- 2
- Met bescherm toestellen:
- Ja
- Grondstof:
- Amaplast
- Aantal geleiders:
- 2 kabels 5x25mm²
- Soort artikel:
- 5 segmenten
- Behoort tot:
- AMAXX®
- CEE 32A, 4P, 400V:
- 0
- DUO 63A, 5P, 400V:
- 1
