AMAXX CEE63A4P400V 2CEE32A,16A4P400V
Artikelreferentie: M953425
MENNEKES receptacle combination unit AMAXX ready wired for installation enclosure protection Type IP 44
enclosure:
1 AMAPLAST-enclosure 650 x 225 mm (h x w) lead-sealable, for internal or external fixing
black base
front cover electric grey RAL 7035
hinged cover with dual thread cover screws
fusing fitted on pull out DIN rails below transparent windows
windows open downwards and can be locked with padlock
receptacles with angled plugging direction
fitted With/fused With:
1 CEE receptacle 63A 4p 400V
2 CEE receptacles 32A 4p 400V 2 MCBs 32A 3p C
2 CEE receptacles 16A 4p 400V 2 MCBs 16A 3p C
1 RCD 63A 4p IFN= 0,3 A
cable entry/supply:
2 M 40 at the top and at the bottom (closed)
2 M 20 at the top and at the bottom (closed)
terminal for 2 cables up to 4 x 25 mm² (flexible max. 16mm²)
Receptacle combination acc. to IEC 61439:
Fuse 63 A
RDF 0,55
InA 63 A
enclosure:
1 AMAPLAST-enclosure 650 x 225 mm (h x w) lead-sealable, for internal or external fixing
black base
front cover electric grey RAL 7035
hinged cover with dual thread cover screws
fusing fitted on pull out DIN rails below transparent windows
windows open downwards and can be locked with padlock
receptacles with angled plugging direction
fitted With/fused With:
1 CEE receptacle 63A 4p 400V
2 CEE receptacles 32A 4p 400V 2 MCBs 32A 3p C
2 CEE receptacles 16A 4p 400V 2 MCBs 16A 3p C
1 RCD 63A 4p IFN= 0,3 A
cable entry/supply:
2 M 40 at the top and at the bottom (closed)
2 M 20 at the top and at the bottom (closed)
terminal for 2 cables up to 4 x 25 mm² (flexible max. 16mm²)
Receptacle combination acc. to IEC 61439:
Fuse 63 A
RDF 0,55
InA 63 A
- Gewicht:
- 9,600 kg / stuk
- Soort artikel:
- 5 segmenten
- Behoort tot:
- AMAXX®
- Beschermingsgraad:
- IP44
- Kleur behuizing:
- Lichtgrijs
- Aansluittechniek:
- 1 terminal
- Wijze van plaatsen:
- Opbouw
- CEE 16A, 4P, 400V:
- 2
- CEE 63A, 4P, 400V:
- 1
- Met bescherm toestellen:
- Ja
- Grondstof:
- Amaplast
- Aantal geleiders:
- 2 kabels 5x25mm²
- Soort artikel:
- 5 segmenten
- Behoort tot:
- AMAXX®
- CEE 32A, 4P, 400V:
- 2
