AMAXX 2NF IP67
Artikelreferentie: M910562
MENNEKES receptacle combination unit AMAXX ready wired for installation enclosure protection Type IP 67
enclosure:
1 AMAPLAST-enclosure 130 x 225 mm (h x w) lead-sealable, for internal or external fixing
black base
front cover electric grey RAL 7035 with dual thread cover screws
fitted with/fused with:
2 receptacles 16A 2p+E 230V (IP 68) french/belgian system, with shutter
cable entry/supply:
2 M 25 at the top and at the bottom (closed)
2 M 20 at the top and at the bottom (closed)
terminal for 1 cable up to 3 x 16 mm²
enclosure:
1 AMAPLAST-enclosure 130 x 225 mm (h x w) lead-sealable, for internal or external fixing
black base
front cover electric grey RAL 7035 with dual thread cover screws
fitted with/fused with:
2 receptacles 16A 2p+E 230V (IP 68) french/belgian system, with shutter
cable entry/supply:
2 M 25 at the top and at the bottom (closed)
2 M 20 at the top and at the bottom (closed)
terminal for 1 cable up to 3 x 16 mm²
- Gewicht:
- 1,700 kg / stuk
- Soort artikel:
- 1 segment
- Behoort tot:
- AMAXX®
- Beschermingsgraad:
- IP67
- Kleur behuizing:
- Lichtgrijs
- Aansluittechniek:
- 1 terminal
- Type beschermcontact:
- Penaarde
- Kinderveiligheid:
- Ja
- Wijze van plaatsen:
- Opbouw
- Contactdoos 16A, 2P+PE, 230V:
- 2
- Met bescherm toestellen:
- Neen
- Grondstof:
- Amaplast
- Aantal geleiders:
- 1 kabel 3x16mm²
- Soort artikel:
- 1 segment
- Behoort tot:
- AMAXX®
- CEE 32A, 4P, 400V:
- 0
