3KRAFT CEE16A5P400V NF 2RJ45 geel IP20
Artikelreferentie: M94355FG
MENNEKES 3KRAFT
ready wired for installation
enclosure protection type IP20
back enclosure made of AMAPLAST black (similar to RAL 9005)
with hinged cover (yellow),
integrated hanging eyelets and standing feet
fitted with/ fused with:
1 CEE-receptacle 16A 5p 400V
2 grounding-type receptacles 16A 2p+E 230V french/belgian system, with shutter
1 RJ45 double UAE cat. 5e 8/8
cable entries for cut-out:
at the top:
1 x M32, 1 x M25, 2 x M20
at the side:
1 x M25
1 x opening for cut-out at the top for pneumatic connection or additional handle
(both available as accessories)
ready wired for installation
enclosure protection type IP20
back enclosure made of AMAPLAST black (similar to RAL 9005)
with hinged cover (yellow),
integrated hanging eyelets and standing feet
fitted with/ fused with:
1 CEE-receptacle 16A 5p 400V
2 grounding-type receptacles 16A 2p+E 230V french/belgian system, with shutter
1 RJ45 double UAE cat. 5e 8/8
cable entries for cut-out:
at the top:
1 x M32, 1 x M25, 2 x M20
at the side:
1 x M25
1 x opening for cut-out at the top for pneumatic connection or additional handle
(both available as accessories)
- Gewicht:
- 1,500 kg / stuk
- Behoort tot:
- 3KRAFT®
- Beschermingsgraad:
- IP44
- Kleur behuizing:
- Geel
- Wijze van plaatsen:
- Draagbaar / Ophangbaar
- CEE 16A, 5P, 400V:
- 1
- Contactdoos 16A, 2P+PE, 230V:
- 1
- Data-aansluiting RJ45:
- 2
- Met bescherm toestellen:
- Neen
- Grondstof:
- Amaplast
- Behoort tot:
- 3KRAFT®
- CEE 32A, 4P, 400V:
- 0
